Product Description

TOKIMEC C5G-815 Directional Control Valve

The TOKIMEC C5G-815 is a high-performance, solenoid-operated directional control valve designed for industrial hydraulic systems. Manufactured by Tokyo Keiki (formerly TOKIMEC), this valve belongs to the C5G series, known for its reliability and robust construction. It utilizes dual solenoids for actuation and is spring-centered. This valve controls the start, stop, and direction of fluid flow, making it suitable for a wide range of machinery applications requiring precise hydraulic control. Its subplate mounting design conforms to international standards, ensuring easy integration and interchangeability.

Technical Specifications:

Valve Type: Solenoid Operated Directional Control Valve
Series: C5G
Model: C5G-815
Valve Size: NG6 / CETOP 03 / NFPA D03
Mounting Standard: ISO 4401-03-02-0-94
Actuation Type: Double Solenoid, Spring Centered
Spool Type Code: 8 (Specific flow path configuration, often Closed Center or similar – refer to datasheet for exact diagram)
Maximum Operating Pressure: Typically up to 31.5 MPa (315 bar / 4568 PSI) or 35 MPa (350 bar / 5075 PSI) – Confirm with specific datasheet
Maximum Flow Rate: Approximately 60-80 L/min (15.8-21.1 GPM) – Confirm with specific datasheet
Hydraulic Fluid: Mineral oil based hydraulic fluid, phosphate ester
Voltage: Requires specification (Common options include 24V DC, 110V AC, 220V AC)
Electrical Connection: Various options available (e.g., DIN connector, terminal box)
