Product Description

OMRON FE-61R Fiber Optic Sensor Amplifier

The OMRON FE-61R is a fiber optic sensor amplifier unit designed for use with OMRON’s extensive range of fiber optic sensing heads (sold separately). This amplifier provides reliable object detection in industrial automation environments. It typically features sensitivity adjustment for optimal performance tuning based on the application requirements and the specific fiber unit employed (through-beam or reflective). LED indicators provide visual confirmation of the operating status and detection stability, simplifying setup and maintenance. Designed for integration into control systems, it operates on standard DC voltage.

Technical Specifications:

Type: Fiber Optic Sensor Amplifier Unit
Compatible Fiber Units: OMRON Through-beam or Reflective types (sold separately)
Light Source: Red LED
Output Type: NPN Open Collector (Note: Confirm specific model suffix if PNP is required)
Response Time: Typically 0.5ms or 1ms (May vary slightly by specific revision)
Power Supply Voltage: 12 to 24 VDC ±10%, ripple (p-p) 10% max.
Current Consumption: Approx. 35 mA max.
Operation Mode: Light-ON / Dark-ON selectable (usually via switch or wiring)
Indicators: Operation indicator (Red LED), Stability indicator (Green LED)
Adjustment: Sensitivity adjustment potentiometer
Connection Method: Pre-wired cable (standard length typically 2m)
Protection Circuits: Output short-circuit protection, Reverse polarity power supply protection
