Product Description

NAKAKITA NS-967F High Performance Butterfly Valve

The NAKAKITA NS-967F is a high-performance butterfly valve designed for reliable flow control in demanding industrial and marine applications. Known for its robust construction and durability, this valve offers excellent sealing capabilities and precise regulation across a range of pressures and temperatures. Its flanged design facilitates secure installation in various piping systems, making it suitable for handling liquids, gases, and steam where high performance and longevity are required.

Technical Specifications:

Valve Type: High Performance Butterfly Valve
Model Series: NS-967F
Connection Type: Flanged End (e.g., JIS 5K/10K/16K, ANSI Class 150)
Body Material: Ductile Cast Iron (FCD450), Cast Steel (WCB/SCPH2), Stainless Steel (SCS13A/SCS14A) – *Specific material depends on order configuration*
Disc Material: Stainless Steel (SUS316/SCS14A)
Seat Material: Reinforced PTFE (RTFE) / PTFE – *Other materials may be available*
Nominal Size Range: DN50 (2″) to DN600 (24″) – *Check specific model variations*
Pressure Rating: Dependent on flange standard and material (e.g., up to 1.96 MPa for JIS 16K)
Temperature Range: Approx. -20°C to +230°C (Dependent on seat and body material)
Actuation: Manual (Lever/Gearbox), Pneumatic, Electric Actuator options available
Application: Marine, Shipbuilding, Chemical Plants, Power Generation, General Industry
