Product Description

FANUC A06B-0061-B006 AC Servo Motor

The FANUC A06B-0061-B006 is an AC Servo Motor belonging to the Beta iS series (specifically model βiS 1/6000). These motors are known for their reliability and high performance in demanding industrial automation applications, particularly in CNC machine tools and robotics. This specific model offers a compact design, efficient operation, and precise motion control capabilities without an integrated brake.

Technical Specifications:

Model Number: A06B-0061-B006
Motor Series: Beta iS (βiS)
Model Type: βiS 1/6000
Motor Type: AC Servo Motor
Rated Output: 0.3 kW
Rated Voltage: 200-240V
Rated Torque: 1 Nm
Maximum Torque: 3 Nm
Rated Speed: 3000 rpm
Maximum Speed: 6000 rpm
Encoder: Absolute Encoder (Specific type may vary, often A860-2000-T301)
Shaft Type: Tapered Shaft (TAP)
Brake: No Brake
Insulation Class: F
Protection Class: Typically IP65 (motor body, excluding shaft end and connector)
