Product Description
Consilium Salwico ST400 Addressable Manual Call Point
The Consilium Salwico ST400 is an addressable manual call point designed for use within Salwico fire detection systems. It allows for manual activation of a fire alarm. The unit features a resettable element, meaning no glass needs to be broken or replaced upon activation; it can be simply reset using a special key. An integrated short-circuit isolator enhances system integrity, and an LED indicator provides visual confirmation of activation. The ST400 is intended for indoor use, commonly found in marine and offshore installations.
Technical Specifications:
- Voltage: 18-32 VDC (Loop powered)
- Current Consumption (Normal): < 0.2 mA
- Current Consumption (Alarm): Approx. 3 mA
- Ingress Protection: IP24D
- Operating Temperature: -25°C to +70°C
- Ambient Humidity: 0 to 95% RH (non-condensing)
- Material: PC/ABS Plastic
- Colour: Red
- Weight: Approx. 160 g
- Dimensions (HxWxD): Approx. 98 x 98 x 47 mm
- System Compatibility: Salwico CS3000, CS4000, NSAC-1
- Features: Resettable element, Integrated short-circuit isolator, LED indication
- Approvals: MED (Check specific variant for full list of approvals)
Consilium ST400
Model:Consilium ST400
