Product Description

CLORIUS ER2000 Electric Actuator

The Clorius ER2000 is a versatile and robust electric rotary actuator designed for the precise control of valves, such as butterfly or ball valves, in heating, ventilation, air conditioning (HVAC), district energy, and various industrial applications. It provides reliable operation for both modulating and 3-point control systems. Featuring a compact design, manual override capability, and clear position indication, the ER2000 ensures ease of installation and dependable performance in demanding environments.

Technical Specifications:

Supply Voltage: 24V AC/DC or 230V AC (model dependent)
Control Signal: 3-point / Modulating (0-10V, 2-10V, 0-20mA, 4-20mA) (model dependent)
Torque: 10 Nm or 15 Nm (model dependent)
Running Time (90°): Approx. 60s / 120s (model and frequency dependent)
Angle of Rotation: Max. 95°, adjustable
Protection Class: IP54
Ambient Temperature: -20°C to +50°C
Manual Override: Yes (Push button and hand lever)
Position Indication: Mechanical scale
Auxiliary Switches: Optional (2 potential-free, adjustable switches)
