Product Description

Bucher WR22G-EZ5-5 Directional Control Valve

The Bucher WR22G-EZ5-5 is a high-performance, direct solenoid-operated directional spool valve. It is designed according to the NG10 (CETOP 5 / NFPA D05) standard interface, ensuring interchangeability. This valve features two solenoids for 3-position control and is spring-centered. The ‘EZ5’ spool configuration typically indicates a closed-center type where ports P, T, A, and B are blocked in the neutral position. It is commonly used in industrial and mobile hydraulic systems to control the direction of fluid flow, enabling the actuation of cylinders or hydraulic motors.

Technical Specifications:

Valve Type: Direct Solenoid Operated Directional Spool Valve
Series: WR22G
Mounting Standard: ISO 4401-05 / DIN 24340-A10 / CETOP 5 / NFPA D05
Nominal Size: NG10
Actuation: 2 Solenoids, Spring Centered
Spool Symbol: EZ5 (Closed Center – P, T, A, B blocked)
Max Operating Pressure (P, A, B): Typically 315 bar (4568 PSI) – *Confirm with specific datasheet*
Max Operating Pressure (T): Typically 160/210 bar (2320/3045 PSI) – *Confirm with specific datasheet*
Max Flow Rate: Approximately 120 l/min (31.7 GPM) – *Dependent on pressure drop*
Solenoid Voltage (-5): Typically 24V DC – *Confirm specific configuration*
Hydraulic Fluid: Mineral oil based (HL, HLP), others on request
Fluid Temperature Range: -20°C to +70°C (Standard NBR seals)
Viscosity Range: 10 to 500 mm²/s (cSt)
